| 材質 | 硅酸鈣 |
|---|---|
| 產地 | 山東 萊州 |
| 產品類別 | 窯爐工業窯爐用保溫材料 |
| 產品種類 | 保溫板 |
| 等級 | A級 |
| 抗彎強度 | 0.60 |
| 使用溫度 | 1000° |
| 形態 | 微孔狀 |
| 形狀 | 板材 |
| 應用范圍 | 工業窯爐 |
| 種類 | 窯爐工業窯爐用保溫材料 |
| 芯材 | 硅酸鈣 |
| 導熱系數（常溫） | 0.035 |
| 品牌 | 保安得 |
硬硅鈣石復合磚性能指標 Calcium Silicate Brick Tech. Data 電解鋁行業 In Aluminium
| 項目 Item | 單位Unit | 標準 According To | MFDJ-30Q | MFDJ-40 |
| 溫度等級 Temperature Limited | ℃ | — | 1000 | 1000 |
| 密度，±10 % Density | kg/m3 | GB/T 10699 | 300 | 400 |
| 抗壓強度 Compress Strength | MPa | GB/T 5072 | ≥1.5 | ≥2.0 |
| 900℃×3 h線收縮 Linear Shrinkage | % | GB/T 10699 | ≤1.0 | ≤1.0 |
| 導熱系數（熱面溫度900℃） Thermal cond.(hot surface at 900C) | W/(m·K) | YB/T 4130 | ≤0.11 | ≤0.11 |
產品描述Deion
產品是無機材料，主晶相是硬硅鈣石，理化性能穩定。
The MFDJ calcium silicate boards are inorganic materials,the main crystal phase is the xonotlite ,with excellent physical and chemical properties.
產品基材是由硅質材料和鈣質材料經蒸壓水熱合成的，均勻分布有大量微米級和納米級孔隙，氣孔率85~91 %，絕熱性能優異。
The product composition is siliceous and calcareous materials,with a large number of micron and nanoscale porosity.
Total porosity 82~91%.
Exceptional heat resistance.
產品是背襯絕熱功能材料，由其性能決定，不能用作爐襯的工作層。
The calcium silicate boards is back-up insulation material in all refractory constructions.Due to its capability, it can not be used as work layer of stove.
產品不含石棉和其它有毒有害成分；沒有生物營養成分，不會腐爛、發霉，沒有蟲害和鼠害危險。
Asbestos free.
Non-toxic
Harmless
No nutrition
Rot-resistant and non-ageing
Insect free
產品特性 Features
熱導系數低，絕熱效果好 Low thermal conductivity, Exceptional heat resistance
熱收縮率低，尺寸穩定 Low lining shrinkage,dimensional stability
體積密度低，熱容量少 Low density, low heat capacity
理化性能穩定，耐久性好 Stable and excellent durability
產品應用 Applications
作為優異的絕熱背襯材料，產品可廣泛用于絕大部分工業領域的熱工設備。
As excellent back-up insulations materials, it can be widely used in high-temperature process equipment.
有色冶金行業，適合于電解槽槽底和側壁的絕熱保溫。
Calcium silicate boards are suitable for electrolyzer tank bottom and wall insulation.
水泥行業 In Cement
| 項目Item | 單位Unit | 標準 According To | MFSN-22 | MFSN-30Q | MFSN-30T | MFSN-50H | |
| 溫度等級Temperature Limited | ℃ | - | 1000 | 1000 | 1000 | 1200 | |
| 密度，±10 % Density | kg/m3 | GB/T 10699 | 220 | 300 | 300 | 550 | |
| 抗折強度 Flexture Strength | MPa | ≥0.33 | ≥0.60 | ≥0.40 | ≥0.6 | ||
| 1000℃×3h線收縮Linear Shrinkage 3h at 1000C | % | GB/T 10699 | ≤2.0 | ≤2.0 | ≤2.0 | - | |
| 1100℃×3 h線收縮 Linear Shrinkage 3h at 1100C | - | - | - | ≤3.0 | |||
| 導 熱 系 數 Thermal Cond. Hot surface at
| 熱面700℃ | W/(m·K) | YB/T 4130 | ≤0.09 | - | - | - |
| 熱面1000℃ | - | ≤0.12 | ≤0.10 | - | |||
| 熱面1100℃ | - | - | - | ≤0.14 | |||
產品描述
產品是無機材料，主晶相是硬硅鈣石，理化性能穩定。
The MFSN calcium silicate boards are inorganic materials,the main crystal phase is the xonotlite ,with excellent physical and chemical properties.
產品基材是由硅質材料和鈣質材料經蒸壓水熱合成的，均勻分布有大量微米級和納米級孔隙，氣孔率79~91 %，其絕熱性能優異。
The product composition is siliceous and calcareous materials,with a large number of micron and nanoscale porosity.
Total porosity 82~91%.
Exceptional heat resistance.
產品是背襯絕熱功能材料，由其性能決定，不能用作爐襯的工作層。
The calcium silicate boards is back-up insulation material in all refractory constructions.Due to its capability, it can not be used as work layer of stove.
產品不含石棉和其它有毒有害成分；沒有生物營養成分，不會腐爛、發霉，沒有蟲害和鼠害危險。
Asbestos free.
Non-toxic
Harmless
No nutrition
Rot-resistant and non-ageing
Insect free
產品特性Features
熱導系數低，絕熱效果好 Low thermal conductivity, Exceptional heat resistance
熱收縮率低，尺寸穩定 Low lining shrinkage,dimensional stability
體積密度低，熱容量少 Low density, low heat capacity
理化性能穩定，耐久性好 Stable and excellent durability
產品應用Applications
作為優異的絕熱背襯材料，產品可廣泛用于絕大部分工業領域的熱工設備。
As excellent back-up insulations materials, it can be widely used in high-temperature process equipment.
水泥行業，適合用預熱器、分解窯、篦冷機和三次風管等設備的絕熱保溫。
Calcium silicate boards are suitable for pre-heater, kiln, cooler and TAD, etc .
